Cryogenic Mill

Ebbecke Verfahrenstechnik offers contract grinding of plastics and special materials.

Contract grinding

Cryogenic grinding of temperature-sensitive products

Special tasks require special measures

As experts in contract grinding, we know: Most materials are easy to grind and can be crushed by mechanical stress such as pressure, shearing, cutting or friction at room temperature.

However, there are also materials for which purely mechanical stress is not sufficient for shredding. This is the case, for example, with polymers (plastics such as PP, PET, PA, etc.), but also with other materials that only deform under mechanical stress instead of breaking. In turn, these materials melt when exposed to heat.

Cold grinding or cryogenic grinding is used to achieve the desired result during grinding.

Cryogenic grinding

Solution for special applications

In cryogenic grinding, temperature-sensitive and lubricating products, including polymers, but also resins, foodstuffs, seeds and fine chemicals, are ground in our Cryogenic Mill.

The advantage of this type of grinding is that it prevents thermal damage and corresponding grinding losses!

In use: innovative grinding systems with vortex screw coolers and liquid nitrogen cooling

The fracture behavior of elastic plastics can be completely changed by using liquid nitrogen. The cooling process causes the glass transition temperature to fall below the temperature. This reduces the material’s ability to withstand high mechanical stresses due to its elastic properties. The result is cold embrittlement of the material – it breaks like glass.

The shape, surface and size of the particles can be influenced using the grinding tool and the appropriate temperature.

Advantages of the process:

The addition of liquid nitrogen also contributes to fire and explosion protection, germ protection and the preservation of active ingredients.

Ideally equipped for every application.

Cryogenic ultrafine grinding for target finenesses

Technical data

Target fineness: 10-2,000 µm
Plant types: Pin mills, beater cross mills
Parts in contact with the product: Stainless steel
Cooling: By means of liquid nitrogen
Delivery as: bagged goods, big bags, octabins, drums
Feeding: Via feeding stations, dosing screws and vortex screw coolers
Filling in: Bags, drums, big bags, cardboard packaging and special containers

Versatile ultrafine grinding for plastics, food and fine chemicals

Areas of application

Our ultrafine grinding covers a wide range of products – from polymers and resins, foodstuffs and seeds to fine chemicals such as vitamins and surfactants. Thanks to state-of-the-art grinding technology, we achieve precise particle size distributions that are optimally matched to the respective material properties and applications. In this way, we guarantee the highest quality and reproducibility in every batch.
