Roller compacting system

A. Ebbecke offers roller compaction for low-dust granulate production - with adjustable pressing force, fine recirculation and powder mixing.

Ebbecke Process Engineering Compacting Icon
Machine detail compacting / granulation at Ebbecke Verfahrenstechnik

The roller compacting system

The solution for low-dust products

Reliable technology for the required product

With our roller compacting system, powdery components can be compacted into pellets with particularly low dust levels. Several components with different properties can also be mixed and granulated together. Our roller compacting system therefore enables the efficient complete production of granulates from powder mixtures.

The systems used at Ebbecke Verfahrenstechnik are equipped with pre-granulators and fine granulators. At the same time, the fines are returned via a post-screening system. The pressing force of all pelletizing systems is infinitely variable. In addition, some of the systems are equipped with pre-compaction by means of vacuum feed.

Low-dust products for easy handling

Technical data

  • Pelletizing capacity: 5-500 kg/h
  • Product intake by means of: pre-compressor screw (two-stage) and vacuum intake (partial)
  • Parts in contact with the product: Stainless steel
  • Feeding from: Big bag, octabin, bagged goods, cardboard packaging, drums
  • Platform construction: All system components are made of stainless materials, as a closed trough, welded
  • Re-screening using a vibrating screening machine or long-stroke screening plant, screen can be pulled out
  • Fines return: continuous by means of suction conveyor and feed to the feed product
Ebbecke Process Engineering Presentation Technical Data

Precise granulate production with optimum properties

Areas of application

Our processes enable the production of granulates with precisely defined hardness and abrasion resistance thanks to infinitely variable contact pressure. This ensures a high level of product homogeneity and prevents segregation. Low-dust granules facilitate handling and improve mixing properties, while the compaction of the material reduces the container volume – while maintaining the same active ingredient content.
